Steam Boiler for Commercial Use in Singapore

Project: Steam Boiler for Commercial Use in Singapore
Industry: Rental
Boiler Type: WNS Series Horizontal Type Fire Tube Steam Boiler
Boiler Model and Quantity: 1 set of WNS6-1.25-YQ

A customer from Singapore ordered a 6-ton diesel-fired steam boiler WNS6-1.25-YQ on 6^th Sept. He has an engineering company and a powerful engineers team. So, he’s going to installation this boiler into a customized container, which will be easy to move it from place to place for rent in Singapore. As you know, boiler exported from China to Singapore needs to be accordance with the standard of ASME and MOM, and we are experienced on the ASME standard boilers, due to we have several boilers exported to USA before. So, we win the trust of this customer and definitely won’t let him down.

Characteristics of WNS series horizontal type fire tube steam boiler:

Corrugated furnace increases heat transfer area and adapts to free expansion;
Waste heat recovery part is composed of finned tubes, made of aluminum-steel alloy, keeping enough heat transfer surface;
Boiler body, economizer, condenser, burner, pump and control system are integrated to ensure easy installation;
Heat transfer elements are composed of threaded flue gas tube instead of smooth tube, which have lower resistance and higher efficiency;
Multiple pressure interlocking protection technique;
Compared with traditional four water level alarms, there is a fifth water level detection device, further strengthening safety automatically;
Wet back two-pass fire tube boiler with reversal burning chamber;
Laddering heat recovery can greatly increase boiler efficiency;
The double-layer sealing structure of front smoke box door and panel adopts aluminium silicate board as insulation material, with high thermal insulation and sealing effect;
Detachable spring explosion-proof door ensures safety, also can be used as inspection hole;
Continuous variable frequency water supply, ensures pump and burner run coordinately and stably.
Waste heat recovery in flue gas lowers exhaust temperature to 95℃, and improves efficiency to 98 .5 %;
Discharge of NO_X , CO_X , SO_X and other harmful substances has been greatly reduced;
The range of steam pressure can be set by touch screen , achieving automatic and accurate control.
