Chemical dosing equipment is a device used to measure, mix, and dispense precise amounts of chemicals or liquids into a process stream or batch. It typically consists of a dosing tank, mixer, metering pump, control panel, piping, valves, and filters. The equipment is designed to handle a variety of chemicals and liquids, including acids, alkalis, polymers, flocculants, disinfectants, and nutrients.
The dosing tank is where the chemicals or liquids are stored before being dispensed. The mixer is used to dissolve and mix the chemicals or liquids in the tank to ensure a homogenous solution. The metering pump is used to accurately deliver the desired amount of the solution into the process stream or batch. The control panel is used to monitor and control the dosing process, ensuring accuracy and safety.
Chemical dosing equipment is widely used in industries such as water treatment, chemical processing, food and beverage, pharmaceuticals, and agriculture. It offers several advantages, including precise and accurate dosing, ease of use, automation, and safety.
Working Principle:
The chemical dosing equipment is mainly composed of a solution tank, a mixer, a metering pump, a liquid level gauge, an electric control cabinet, pipelines, valves, filters, etc. (configurable according to the actual requirements of the user).
The chemical dosing device prepares the solution in the stirring tank according to the required concentration of the medicine. After being evenly stirred by the agitator, it is put into the solution tank, and the prepared solution is delivered to the dosing point or the designated system by a metering pump (dosing pump). The chemical dosing device has a compact structure, is simple to operate and use. It can also be designed and configured with necessary components according to the specific requirements of different user processes to achieve suitable functions (such as automatic remote control) that are economical and practical.
Structural Characteristics:
-
Material: The main raw material is new linear low-density polyethylene (LLDPE).
-
Process: Rotational molding
-
Properties: It has features such as corrosion resistance, acid and alkali resistance, impact resistance, aging resistance, UV resistance, cleanliness, and hygiene.
-
Main components: Metering bucket, agitator, metering pump, control cabinet, control system, 304 stainless steel/carbon steel platform, etc. (Customized installation is available based on specific requirements.)
-
Function: The agitator dissolves the chemical in the metering bucket, and the control system controls the metering pump to add a specified dosage of the chemical into the reaction tank.
Application:
-
Environmental water treatment (metering, stirring, mixing, adjustment, etc. of water treatment chemicals such as PAM, PAC, sodium hypochlorite, carbon source, sodium acetate, scale inhibitor, corrosion inhibitor, bactericidal algicide, etc.)
-
Agricultural irrigation industry (supporting products for water and fertilizer integration equipment, solid mixing of water fertilizer, liquid fertilizer, etc.)
The chemical dosing device is an integrated equipment that combines metering, stirring, liquid delivery, and automatic control. Chemical dosing equipment is widely used in power plants, boiler feed water, oil field ground gathering and transportation dehydration treatment systems, various petrochemical metering and dosing systems, and metering wastewater treatment systems. For example, adding PAM/PAC, ammonia liquid, lime water, water quality stabilizer (corrosion inhibitor), scale inhibitor, liquid insecticide, etc.
